STAINLESS STEEL TUBESTAINLESS STEEL TUBE
Quality Oriented Manufacturer
of Medical Needle Products
| Gauge |
Cannula Outer Diameter |
| 32G |
0.230mm |
| 31G |
0.250mm |
| 30G |
0.300mm |
| 28G |
0.330mm |
-
01
Introduction
TaeChang Stainless steel tube complies with ISO 15510 and ISO 9626 standards.
-
02
Stainless Steel Tube
Produced from SUS304 stainless steel tube.
The cutting-edge laser welding technique used.
Customized tube available.
-
03
Specification
Specification For Stainless Tube
| Size |
Dutside Diameters |
Inner Diameter |
| Gauge |
Nomial |
Min |
Max |
Normal wall |
Thin-wall |
Extra-thinwall |
| Min |
Max |
Min |
| 32G |
0.230 |
0.229 |
0.241 |
0.089 |
0.105 |
|
| 31G |
0.250 |
0.254 |
0.267 |
0.114 |
0.125 |
|
| 30G |
0.300 |
0.298 |
0.320 |
0.113 |
0.165 |
|
| 29G |
0.330 |
0.324 |
0.351 |
0.133 |
0.190 |
|
| 28G |
0.360 |
0.349 |
0.370 |
0.133 |
0.190 |
|
| 27G |
0.400 |
0.400 |
0.420 |
0.184 |
0.241 |
|
| 26G |
0.450 |
0.440 |
0.470 |
0.232 |
0.292 |
|
| 25G |
0.500 |
0.500 |
0.530 |
0.232 |
0.292 |
|
| 24G |
0.550 |
0.550 |
0.580 |
0.280 |
0.343 |
|
| 23G |
0.600 |
0.600 |
0.650 |
0.317 |
0.370 |
0.460 |
| 22G |
0.700 |
0.698 |
0.730 |
0.390 |
0.440 |
0.522 |
| 21G |
0.800 |
0.800 |
0.830 |
0.490 |
0.547 |
0.610 |
| 20G |
0.900 |
0.860 |
0.920 |
0.560 |
0.635 |
0.687 |
| 19G |
1.100 |
1.030 |
1.100 |
0.648 |
0.750 |
0.850 |
| 18G |
1.200 |
1.200 |
1.300 |
0.790 |
0.910 |
1.041 |
| 17G |
1.400 |
1.400 |
1.510 |
0.950 |
1.156 |
1.244 |
| 16G |
1.600 |
1.600 |
1.690 |
1.100 |
1.283 |
1.390 |
| 15G |
1.800 |
1.750 |
1.900 |
1.300 |
1.460 |
1.560 |
| 14G |
2.100 |
1.950 |
2.150 |
1.500 |
1.600 |
1.727 |
| 13G |
2.400 |
2.300 |
2.500 |
1.700 |
1.956 |
|
| 12G |
2.700 |
2.650 |
2.850 |
1.950 |
2.235 |
|
| 11G |
3.000 |
2.950 |
3.150 |
2.200 |
2.464 |
|
| 10G |
3.400 |
3.300 |
3.500 |
2.500 |
2.819 |
|
